8-Port 2.5GbE Switch with one SFP+ Port

Unmanaged Layer 2 Switch with 10G uplink

Blue Background

Product Highlights

The SW08M01X unmanaged switch offers 8x 2.5GbE and 1x 10G SFP+ ports, allsupporting full wire-speed forwarding at 2.5Gbps/10Gbps. Its high capacity switchchip ensures fast and efficient transmission of large files, making it perfect for highbandwidth applications. It’s a versatile and cost-effective solution suitable for hotels, banks, campuses, factories, and small to medium-sized enterprises.

  • 8x 100M/1G/2.5GbE Ports

  • 1x 10GbE SFP+ Uplink Port

  • LED Indicator for Each Port

  • 12V/1A Power adapter

  • FCC/CE Certification

Technical Specifications

I/O Interface

  • Interface 8x 2.5GbE RJ45

  • 1x 10G SFP+

Link rate

  • 2.5G auto negotiation for RJ45

  • 10G fixed rate for SFP+

Jumbo frame

  • Up to 12KB

Switch capacity

  • 60Gbps

MAC table

  • 4K MAC addresses

Flow control

  • IEEE 802.3x

  • Back pressure

Power

  • 12V/1A

Dimensions

  • 190mm*100mm*28mm

Lighting protection

  • 6KV Common-mode

  • 8KV Air Discharge Surge

  • 6KV Contact Discharge

Warranty

  • Warranty 1 years

Network protocol

  • IEEE 802.3

  • IEEE 802.3u

  • IEEE 802.3ab

  • IEEE 802.3bz

  • IEEE802.3ae

EEE

  • IEEE 802.3az

Packet buffer

  • Built-in SRAM

Forwarding rate

  • Maximum 44.6Mpps

LED

  • Power

  • Indicators per port

Environmental

  • Operating temperature: 0~40°C

  • Storage temperature: -40~70°C

  • Operating humidity: 10%~90%, non-condensing

  • Storage humidity: 5%~95%, non-condensing

Mounting

  • Desktop

Weights

  • 0.49Kg​

Certifications

  • FCC, CE
